Estándar y protocolo
IEEE802.3，IEEE802.3u，IEEE802.3ab
Interfaz
1*10/100Mbps WAN port
3*10/100Mbps LAN ports
3*10/100Mbps LAN ports
Antena
4*6dBi external high-gain antennas
Botones
1*WPS/Reset button
Potencia
Input：AC 100-240V—50/60Hz
Output：DC 9V 1A
Output：DC 9V 1A
LED
1*LED
Dimensiones
200x127x33.6mm(L*W*H)
Estándar inalámbrico
IEEE 802.11ac/a/n @5GHz
IEEE 802.11b/g/n @2.4GHz
IEEE 802.11b/g/n @2.4GHz
Velocidad
2.4GHz: 300Mbps
5GHz: 867Mbps
5GHz: 867Mbps
Frecuencia
2.400 – 2.4835 GHz
5.150 – 5.250 GHz
5.150 – 5.250 GHz
Seguridad inalámbrica
WPA-PSK/WPA2-PSK, WPA/WPA2
Wireless Security : Enable /Disable
Wireless Security : Enable /Disable
Tipo de conexión a Internet
PPPoE, Dynamic IP, Static IP
Support automatic access detection
Supports broadband account automatic transfer
Support automatic access detection
Supports broadband account automatic transfer
Modo de funcionamiento
Wireless Router Mode
AP Mode
Universal Repeater mode
WISP Mode
AP Mode
Universal Repeater mode
WISP Mode
DHCP
DHCP Server
DHCP Client List
DHCP Reservation
DHCP Client List
DHCP Reservation
Servidor virtual
Port Forwaring
DMZ Host
UPnP
DMZ Host
UPnP
Seguridad
Client Filter（supports black list and white list）
Parental Control（supports black list and white list）
Remote Web Management
Parental Control（supports black list and white list）
Remote Web Management
Firewall
Forbid WAN PING from internet
DDNS
Support DynDNS, 88ip
Other features
Support IPv6
Broadband management
MAC address clone
Static Routing
System Log
Backup & Restore configurations
Firmware upgrade from local
Broadband management
MAC address clone
Static Routing
System Log
Backup & Restore configurations
Firmware upgrade from local
Temperatura
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.
Storage Temperature: -40℃ ~ 70℃.
Humedad
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Storage Humidity: 5% ~ 90%RH non-condensing.
Certificaciones
CE，RoHS，FCC，CCC，SRRC，
EIRP Power (Max.)
2.400 – 2.4835 GHz：19.85 dBm (EIRP)
5.150 – 5.250 GHz：22.96dBm (EIRP)
5.150 – 5.250 GHz：22.96dBm (EIRP)
