Especificaciones
- Cámara
- Sensor De Imagen1/2.4″ Progressive Scan CMOS
- Max. Resolución3200 × 1800
- Iluminación MínimaColor: 0.003 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
- Tiempo De Obturación1/3 s to 1/100,000 s
- Día Y NocheIR cut filter
- Ajuste De ÁnguloPan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
- Lente
- LenteFixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 105.1°, vertical FOV 53.4°, diagonal FOV 128.6°
4 mm, horizontal FOV 83.9°, vertical FOV 44.5°, diagonal FOV 100.8°
- Montura Del LenteM12
- Iris TypeFixed
- AperturaF1.6
- DORI
- DORI
2.8 mm: D: 78.6 m, O: 31.2 m, R: 15.7 m, I: 7.9 m
4 mm: D: 95.6 m, O: 37.9 m, R: 19.1 m, I: 9.6 m
- Iluminador
- Tipo De Luz SuplementariaIR
- Rango De Luz SuplementariaUp to 30 m
- Luz De Suplemento InteligenteYes
- IR Wavelength850 nm
- Vídeo
- Main Stream
50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360),
*Third stream is supported under certain settings.
- Vídeo Bitrate32 Kbps to 16 Mbps
- Tipo H.264Baseline Profile,Main Profile,High Profile
- Tipo H.265Main Profile
- Bit Rate ControlCBR,VBR
- Codificación De Video Escalable (SVC)H.264 and H.265 encoding
- Compresión De Video
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264 (*Third stream is supported under certain settings.)
- Región De Interés (ROI)1 fixed region(s) for main stream and sub-stream
- Recorte ObjetivoYes
- Audio
- Tipo De Audio-U: Mono sound
- Compresión De Audio-U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC
- Velocidad De Bits De Audio-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
- Frecuencia De Muestreo De Audio-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Filtro De Ruido Ambiental-U: Yes
- Red
- ProtocolosTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
- Vista En Vivo SimultáneaUp to 6 channels
- APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
- Usuario/Operador
Up to 32 users
3 user levels: administrator, operator, and user
- SeguridadPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Almacenamiento En RedNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- ClienteiVMS-4200,Hik-Connect,Hik-Central
- Navegador Web
Plug-in required live view: IE 10+,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+,
Local service: Chrome 57.0+, Firefox 52.0+
- Imagen
- Interruptor De Parámetros De ImagenYes
- Configuración De ImagenRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Interruptor Día/NocheDay,Night,Auto,Schedule
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 52 dB
- Mejora De La ImagenBLC,HLC,3D DNR
- Máscara De Privacidad4 programmable polygon privacy masks
- Interfaz
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
- Micrófono Incorporado-U: Yes
- Reset KeyYes
- Audio
-S: 1 input (line in), max. input amplitude: 3.3 vpp, input impedance:4.7 KΩ, interface type: non-equilibrium; 1 output (line out), max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
- Alarma-S: 1 input, 1 output (TTL: max. 12 VDC, 30 mA)
- Evento
- Evento BásicoMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception, alarm input and output (-S)
- Evento InteligenteLine crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)),Scene change detection
- LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output (-S), audible warning (-S)
- Deep Learning Function
- Captura De La Cara
Yes
- General
- Alimentación
12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.15 A, max. 7.5 W
- Dimensión
Ø121.4 mm × 92.2 mm (Ø4.8 × 3.6″)”
- MaterialAluminum alloy body, bubble: plastic
- Dimensión Del Paquete150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
- Approx. 550 g (1.2 lb.)
- Con Peso Del PaqueteApprox. 800 g (1.8 lb.)
- Condiciones De Almacenaje-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Condiciones De Inicio Y Funcionamiento-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Idioma
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Función GeneralHeartbeat,anti-flicker,mirror,flash log,password reset via email,pixel counter
- Certificaciones
- EMC
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
KC: KN32: 2015, KN35: 2015
- Seguridad
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
- Ambiente
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- ProtecciónIP67: IEC 60529-2013;IK10: IEC 62262:2002
